DC Voltage Sensor CYVT01-48H2, Output: 0-20 mA DC, Power Supply: 85 V ~ 265 V AC

DC Voltage Sensor CYVT01-48H2, Output: 0-20 mA DC, Power Supply: 85 V ~ 265 V AC
Quantity Unit price
until 4 € 116.68 *
from 5 € 106.06 *
from 10 € 96.43 *

Prices incl. VAT excl. Shipping Costs

Article not in stock, Delivery time 3-4 Weeks

Nominal Input Voltage:

Description Technical Properties Data Sheets Product Safety Information
Description
The CYVT01-xnU0 DC voltage sensor/transducer works according to Linear Photoelectrical Isolation... more
Close menu
DC Voltage Sensor CYVT01-48H2, Output: 0-20 mA DC, Power Supply: 85 V ~ 265 V AC

The CYVT01-xnU0 DC voltage sensor/transducer works according to Linear Photoelectrical Isolation and is designed for applications to measurement and monitoring of DC voltage. The output signal (DC voltage or current) of this transducer is proportional to the input DC voltage. They are suitable for measurements and long time monitoring of DC voltages and can applied to power supply management, DC motor drivers, battery chargers and systems etc.



Information about product safety:

Manufacturer/ EU Responsible Person:

Company name: ChenYang Technologies GmbH & Co.KG

Address: Markt Schwabener Str. 8; 85464 Finsing; Deutschland

E-Mail: info@chenyang.de



Phone: +49 8121 2574100



Technical Properties
more
Close menu
Current Type: DC
Input Voltage Range: 0-10mV DC, 0-20mV DC, 0-50mV DC, 0-100mV DC, 0-200mV DC, 0-500mV DC, 0-1V DC, 0-2V DC, 0-5V DC, 0-10V DC, 0-20V DC, 0-50V DC, 0-100V DC, 0-200V DC, 0-500V DC, 0-1000V DC
Thermal drift: 200ppm/°C
Direction: unidirectional
Operating Temperature: -25°C ~ +70°C
Isolation voltage: 2.5 kV DC, 1min, 1.5 kV DC, 1min
Response Time: ≤350ms
Accuracy: 0,2%
Output Signal: 0-20 mA DC
Power Supply: +85 ~ +265 V AC
Data Sheets
more
Close menu
Data sheets to download:
Product Safety Information
Daten zum Produkthersteller more
Close menu

Manufacturer:

Company name: ChenYang Technologies GmbH & Co.KG

Address: Markt Schwabener Str. 8; 85464 Finsing; Deutschland

E-Mail: info@chenyang.de

Phone: +49 8121 2574100

Similar products Customers also bought Customers also viewed
Similar products
DC Voltage Sensor CYVT01-34U0, Output: 0-5 V DC, Power Supply: +24 V DC DC Voltage Sensor CYVT01-34U0, Output: 0-5 V...
from € 92.11 *
DC Voltage Sensor CYVT02-32U0, Output: 0-5 V DC, Power Supply: +12 V DC DC Voltage Sensor CYVT02-32U0, Output: 0-5 V...
from € 66.50 *
DC Voltage Sensor CYVT02-54U0, Output: 4-20 mA DC, Power Supply: +24 V DC DC Voltage Sensor CYVT02-54U0, Output: 4-20 mA...
from € 76.15 *
