Unidirectional DC Voltage Sensor CYVT02-32S2, Output: 0-5 V DC, Power Supply: +12 V DC

Preview: Unidirectional DC Voltage Sensor CYVT02-32S2, Output: 0-5 V DC, Power Supply: +12 V DC Preview: Unidirectional DC Voltage Sensor CYVT02-32S2, Output: 0-5 V DC, Power Supply: +12 V DC
Unidirectional DC Voltage Sensor CYVT02-32S2, Output: 0-5 V DC, Power Supply: +12 V DC
Unidirectional DC Voltage Sensor CYVT02-32S2, Output: 0-5 V DC, Power Supply: +12 V DC

Quantity Unit price
until 4 € 76.45 *
from 5 € 69.50 *
from 10 € 63.18 *

Prices incl. VAT excl. Shipping Costs

Article not in stock, Delivery time 3-4 Weeks

Nominal Input Voltage:

Description Technical Properties Data Sheets
Description
The CYVT02-32S2 DC voltage sensor/transducer works according to Electromagnetic Induction and is... more
Close menu
Unidirectional DC Voltage Sensor CYVT02-32S2, Output: 0-5 V DC, Power Supply: +12 V DC

The CYVT02-32S2 DC voltage sensor/transducer works according to Electromagnetic Induction and is designed for applications to measurement and monitoring of DC voltage. The output signal (DC voltage or current) of this transducer is proportional to the input DC voltage. They are suitable for measurements and long-time monitoring of DC voltages and can be applied to power supply management, DC motor drivers, battery chargers and systems etc.

Technical Properties
more
Close menu
Current Type: DC
Input Voltage Range: 0-10mV DC, 0-50mV DC, 0-75mV DC, 0-1V DC, 0-5V DC, 0-10V DC, 0-50V DC, 0-75V DC , 0-100V DC, 0-200V DC, 0-500V DC, 0-1000V DC
Power Supply: +12V DC
Response Time: ≤400ms
Direction: unidirectional
Isolation voltage: 2.5 kV DC, 1min
Operating Temperature: -10°C ~ +60°C
Accuracy: 0,5%
Output Signal: 0-5V DC
Data Sheets
more
Close menu
Data sheets to download:
